AC.BC Series
  1. The structure is delicate and compact, which is convenient for installation andapplication.
  2. The pressed-in self-locking mechanism can prevent the abnormal movementof the set pressure caused by externalinterfere.
  3. The pressure loss is low and the efficiency of water separating is high.
  4. The quantity of oil dripping can be directly observed through transparentcheck-dome.
  5. ln addition to standard type, lower pressure type is optional (The highestadjustable pressure is 0.4MPa).
Request Quote

Product Details

ModalAC1500AC2000BC2000BC3000BC4000
FluidAir
Port size1/8″1/4″1/4″3/8″1/2″
Filtering grade40 μ m or 5 μ m
Pressure rangeSemi-auto and automatic drain:0.15~0.9Mpa(20~130Psi)                                         Manual drain:0.05~0.9Mpa(7~130Psi)
Max.pressure1.0Mpa(145Psi)
Proof pressure1.5Mpa(215Psi)
Temperature range -5~70℃（unfreeze)
Capacity of drain bowl15CC60CC
Capacity of oil bowl25CC90CC
Recommended lubricantISO VG 32 or equivalent
ConstituteFilterAF1500AF2000BF2000BF3000BF4000
RegulatorAR1500AR2000BR2000BR3000BR4000
LubricatorAL1500AL2000BL2000BL3000BL4000
