| General technical data | ||||||||||
| Size | Mini | Midi | Maxi | |||||||
| Pneumatic connection 1, 21) | G1/8,G1/4,G3/8 | G1/4,G3/8,G1/2,G3/4 | G1/2,G3/4,G1 | |||||||
| Design | Filter regulator with/without pressure gauge | |||||||||
| Proportional standard mist lubricator | ||||||||||
| Type of mounting | Via accessories | |||||||||
| In-line installation | ||||||||||
| Mounting position | Vertical +5° | |||||||||
| Grade of filtration | {um} | 5 | ||||||||
| 40 | ||||||||||
| Bowl guard | Metal bowl guard | |||||||||
| Condensate drain | Manual, rotary | |||||||||
| Fully automatic | ||||||||||
| Actuator lock | Rotary knob with latch | |||||||||
| Rotary knob with integrated lock | ||||||||||
| Pressure regulation range | {bar} | 0.5 … 7 | ||||||||
| 0.5 … 12 | ||||||||||
| Max. pressure hysteresis | {bar} | 0.2 | 0.4 | |||||||
| Pressure indication | With pressure gauge | |||||||||
| Prepared for G1/8 | Prepared for G1/4 | Prepared for G1/4 | ||||||||
