Description
| Series | SY3000 | SY5000 | SY7000 | SY9000 | |
| Fluid | Air | ||||
| Internal pilot Operating pressure range (MPa) | 2 position single | 0.15 to 0.7 | |||
| 2 position double | 0.1 to 0.7 | ||||
| 3 position | 0.2 to 0.7 | ||||
| Ambient and fluid temperature (℃) | 0 to 50 (No freezing) | ||||
| Max. operating frequency (Hz) | 2 position single, double | 10 | 5 | 5 | 5 |
| 3 position | 3 | 3 | 3 | 3 | |
| Manual override (Manual operation) | Non-locking push type, Push-turn locking slotted type, Push-turn locking lever type | ||||
| Pilot exhaust method | Common exhaust type for main and pilot valve | ||||
| Mounting orientation | Unrestricted | ||||
