| Bore size(mm) | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 | |
| Acting | Double acting, Single rod | ||||||||||
| Fluid | Air | ||||||||||
| Proof pressure | 1.5 Mpa | ||||||||||
| Maximum operating pressure | 1.0 Mpa | ||||||||||
| Minimum operating pressure | 0.07 Mpa | 0.05 Mpa | |||||||||
| Ambient and fluid temperatures | Without auto switch magnet: –10 to 70°C (No freezing) With auto switch magnet: –10 to 60°C | ||||||||||
| Lubrication | Not required (Non-lube) | ||||||||||
| Piston speed | 50~500 mm/s | ||||||||||
| Cushion | Without cushion or With rubber bumper | ||||||||||
| Allowable kinetic energy[J] | Without cushion | 0.022 | 0.038 | 0.055 | 0.09 | 0.15 | 0.26 | 0.46 | 0.77 | 1.36 | 2.27 |
| With rubber bumper | 0.043 | 0.075 | 0.11 | 0.18 | 0.29 | 0.52 | 0.91 | 1.54 | 2.71 | 4.54 | |
