| Bore size (mm) | 6 | 10 | 15 | 20 | 25 | 32 |
| Bearing type | Slide bearing | |||||
| Minimum operating pressure | 0.2MPa | 0.15MPa | 0.1MPa | |||
| Piston speed | 50 to 800 mm/s | 50 to 700 mm/s | 50 to 600 mm/s | |||
| Other specifications | Same as the standard model | |||||
| Dimensions | See below | |||||
| Model | K | L | R |
| CXS_ 10 | 4 | 25 | 35 |
| CXS_ 15 | 3 | 36 | 44.5 |
| CXS_ 20 | 6 | 36 | 50.5 |
| CXS_ 25 | 6 | 36 | 52 |
| CXS_ 32 | 4 | 40 | 66 |
| Stroke Model | SS | ||||||||||||||
| 10 | 15 | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 60 | 70 | 75 | 80 | 90 | 100 | |
| CXS_ 10 | 70 | 78 | 80 | 85 | 90 | 95 | 100 | 105 | 110 | 120 | 130 | 135 | / | / | / |
| CXS_ 15 | 76 | 84 | 86 | 91 | 96 | 101 | 106 | 111 | 116 | 126 | 136 | 141 | 146 | 156 | 166 |
| CXS_ 20 | 86 | 91 | 96 | 101 | 106 | 111 | 116 | 121 | 126 | 136 | 146 | 151 | 156 | 166 | 176 |
| CXS_ 25 | 88 | 93 | 98 | 103 | 108 | 113 | 118 | 123 | 128 | 138 | 148 | 153 | 158 | 168 | 178 |
| CXS_ 32 | 102 | 107 | 112 | 117 | 122 | 127 | 132 | 137 | 142 | 152 | 162 | 167 | 172 | 182 | 192 |
